3.2.2 Product features and functions (overview)
Table 3: Overview of product features and functions of the device
Product feature/func‐
tion
Characteristic
Safety and ease of
use
•
Rugged, compact metal housing, CE marking
•
Laser Class 2, laser switches off if the output power is exceeded
•
Automatic self-test on system start
•
Diagnostic tools for system setup and (remote) system monitoring
•
Configurable output of reading diagnostic data in two reading
results formats
•
Operating data polling, in case of error, issue of error code if
required
•
Test string function (heartbeat) can be activated to signal that the
device is ready for operation
•
Password-protected configuration mode via SOPAS ET
•
Future-oriented by firmware update (FLASH PROM) via data inter‐
face
•
Future-oriented SOPAS ET configuration software
•
Low power consumption
•
Additional supply voltage range
•
Optional parameter cloning with external CMC600 parameter
memory module in the CDB/CDM connection module
Convenient operation/
configuration
•
Configuration (online/offline) via SOPAS ET configuration soft‐
ware
•
Configuration via GSD configuration (via CDF600-2xx)
•
Status displays via LEDs
•
Auto setup of the optical reading properties
•
Two pushbuttons on the device to call up preset functions without
connecting a computer
•
Buzzer, which can be switched off, to confirm the device function
•
Application and network setup assistant
Read operation modes
•
Start/stop operation (one bar code bearing object per read pulse)
•
Tracking operation
Read cycle
•
Pulse sources for start: switching inputs, data interface (com‐
mand), auto pulse, free, CAN
•
Pulse sources for stop: read pulse source, switching inputs, data
interface (command), timer, condition
Bar code evaluation
•
All current 1D bar code types
•
Max. number of bar codes: 50 per reading interval
•
Separation of identical codes of the same code type using the
read angle
Data processing
•
Influencing the output of the reading data by event-dependent
evaluation conditions
•
Influencing the output string by filtering and output sorting
Data communication
•
Host interface: two data output formats can be configured, can
be switched to various physical interfaces, parallel operation pos‐
sible
•
Aux interface: fixed data output format, can be switched to vari‐
ous physical interfaces
3.2.3 Operating principle
The device consists of a laser scanner (laser diode and optics), an electronics unit with
integrated decoder and interfaces (type-dependent) to industrial bus systems. The use
of various focusing settings, resolutions, scan processes, bus systems, mounting
options and optics enables use in most industrial applications. Interfaces to external
