Supply voltage DC 21.6 V ... 28.8 V
•
The electricity source must be able to release 144 W power or a maximum of 6 A
for a short time. The switching on current of the device is a maximum of 5.5 A for
1 to 2 ms (depending on the length of the supply cable).
•
Additional 0.5 W output power when using the optional CMC600 parameter mem‐
ory module in the corresponding connection modules
1. Connect supply voltage to the 5-pin M12 male connector “CAN 1” on the cloning
plug with a suitable cable [SV = red (1), GND = blue (2), shield = gray].
2. Switch on the supply voltage and check the device start-up: device in operation?
(Status LEDs illuminate; mirror wheel activates.) A successfully passed test will
confirm that the supply line is connected correctly, and the GND wire in particular.
3. Connect connection cables to external components (e.g. fan, PC via serial inter‐
face, Ethernet) on the cloning plug.
Protecting the supply cables
To ensure protection against short-circuits and overload in the customer’s supply
cables, the conductor cross sections used must be appropriately selected and pro‐
tected.
The following standards must be observed in Germany:
•
DIN VDE 0100 (part 430)
•
DIN VDE 0298 (part 4) and/or DIN VDE 0891 (part 1)
The infeed of the supply voltage is carried out using a SICK connection module or the
customer's voltage supply.
6.6.2 Wiring data interfaces
Wiring Ethernet interface
1. Connect the device to the Ethernet connection of the PC via the adapter cable.
2. Set up communication via SOPAS ET configuration software.
NOTE
The Ethernet interface for the device has an Auto-MDIX function. This automatically
adjusts the transmission speed as well as any necessary crossover connections.
Wiring the serial data interfaces
The maximum data transmission rate for the serial interface depends on the cable
length and on the type of interface. The following recommendations apply:
Table 8: Data transmission rates
Interface type Data transmission rate Distance to the target computer
(host)
RS-232 Up to 19.2 kBd
38.4 kBd ... 57.6 kBd
115.2 kBd … 500 kBd
Max. 10 m
Max. 3 m
Max. 2 m
RS-422/485
1)
Up to 38.4 kBd
38.4 kBd ... 57.6 kBd
Max. 1200 m
Max. 500 m
1)
For RS-422/485-suitable cable and corresponding cable termination as per specification
6 ELECTRICAL INSTALLATION
46
O P E R A T I N G I N S T R U C T I O N S | CLV69x 8014396/ZMG8/2017-07-04 | SICK
Subject to change without notice
