SICK CLV69x User Manual

Connection module CDM490-0001 (I/O card)
SCANNER
I/O
41 42 43 44 45 46
Result 4 GND
Result 3
GND Result 1 Result 2
5 6 7 8
Shield Shield Shield Shield
For CLV69x
("I/O")
51 52 53 54 55 56
GND GND +24V* GND +24V* +24V*
61 62 63 64 65 66
IN 2 IN 3 IN 1 IN 4 Sensor 1 IN 0
71 72 73 74 75 76
GND Reserve GND Reserve GND GND
External sensor
for reading cycle
(e.g. photoelectric
sensor)
U
V
Out
GND
IN
0
1
2
3
4
Sensor
OUT
On basic card
1016 5
11 15
LED
S1
ON
OFF
SGND
Figure 69: Wiring overview, part 2 (I/O map top right), 1 switching input used
6
ELECTRICAL INSTALLATION
76
O P E R A T I N G I N S T R U C T I O N S | CLV69x 8014396/ZMG8/2017-07-04 | SICK
Subject to change without notice
