0
a: Remission 6 %
b: Remission 10 %
c: Remission 18 %
d: Remission 90 %
a
b c d
0
Distance in m (ft)
2
(0.08)
4
(0.16)
6
(0.24)
8
(0.31)
10
(0.39)
12
(0.47)
14
(0.55)
16
(0.63)
Typ. repeatability in mm (inch)
50
(164)
100
(328)
150
(492)
200
(656)
250
(820)
300
(984)
350
(1.148)
Figure 35: DT1000 repeatability with 4 ms measurement cycle time
0
0
a: Remission 6 %
b: Remission 10 %
c: Remission 18 %
d: Remission 90 %
a
b
c
d
Distance in m (ft)
2
(0.08)
4
(0.16)
6
(0.24)
8
(0.31)
10
(0.39)
12
(0.47)
14
(0.55)
16
(0.63)
Typ. repeatability in mm (inch)
50
(164)
100
(328)
150
(492)
200
(656)
250
(820)
300
(984)
350
(1.148)
400
(1.312)
Figure 36: DT1000 repeatability with 16 ms measurement cycle time
