Byte 3 and 2 status
double word
Error/Warning Cause and measures
0x0000 (No warning or error,
device OK)
-
Table 33: Definition of device status double word
Byte Bits Device state Grouping (for
SSI status
bits)
Status bit
assignment/
SSI24+1
Status bit
assignment/
SSI24+8
3 31 Error laser
Device error
(DE)
Bit 0
Bit 7
30 Error hardware
29 Error measurement
28 Error temperature
Application
error (AE)
Bit 6
27 Error ambient light
26 Reserved
25 Reserved
24 Reserved
2 23 Warning: Laser
Device warn‐
ing (DW)
Bit 5
22 Firmware warning
21 Warning: Short-circuit at
switching output
Application
warning (AW)
Bit 4
20 Warning: Temperature
19 Warning: Ambient light
18 Reserved
17 Reserved
16 Reserved
1 15 Alignment laser active
14 Measurement laser active
13 Heating active
12 No echo: delay time active
11 No echo
10 Status In2
9 Status Q4 Bit 3
8 Status Q3 Bit 2
0 7 Status Q2 Bit 1
6 Status Q1/In1 Bit 0
5 Reserved
4 Level Q4
3 Level Q3
2 Level Q2
1 Level Q1/In1
0 Reserved
10.1 Information for the service case
You should collect and write down the following device information ahead of time if you
need to contact the manufacturer's service department:
TROUBLESHOOTING 10
8019329/12TZ/2019-03-28 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000
93
Subject to change without notice
