Alignment bracket (optional)
max. 120 (4.72)
115 (4.53)
97 (3.82)
112.5 (4.43)
106 (4.17)
Ø 5,4
50 (1.97)
13
4
4
Ø 5,4
94 (3.70)
30
90.5 (3.56)
8 (0.31)
4
(0.16)
33
(1.30)
42
(1.65)
Ø 5.4
(0.21)
Ø 5.4
(0.21)
115 (4.53)
97 (3.82)
4
(0.16)
Figure 40: Alignment bracket (dimensions in mm (inch))
172 (6.77)
90.5 (3.56)
106 (4.17)
94 (3.70)
Figure 41: Alignment bracket with device (dimensions in mm (inch))
11
TECHNICAL DATA
106
O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000 8019329/12TZ/2019-03-28 | SICK
Subject to change without notice
