Designation Syntax
Heater off permanently
--> Response OK
<STX>sMN switchHeaterOff<ETX>
<STX>sAN switchHeaterOff<ETX>
Heater automatic mode
--> Response OK
<STX>sMN switchHeaterAuto<ETX>
<STX>sAN switchHeaterAuto<ETX>
Writing preset values
--> Response OK
Value coded in hexadeci‐
mals, unit in mm,
-1500 m ... 1500 m, corre‐
sponds to FFE91CA0 ...
16E360, note: 32 bit!)
<STX>sWN preset <n*[0…F]><ETX>
<STX>sWA preset<ETX>
Read preset
--> Response OK
<STX>sRN preset<ETX>
<STX>sRA preset <n* [0...F]><ETX>
Activating preset
--> Response
Distance output value is
set to the preset value for
the current distance
<STX>sMN activatePreset<ETX>
<STX>sAN activatePreset<ETX>
Setting output to 0
--> Response OK
Distance value output is
set to 0 for the current dis‐
tance
<STX>sMN autoZero<ETX>
<STX>sAN autoZero<ETX>
Deleting preset value
--> Response OK
Distance output value cor‐
responds to the real mea‐
sured value, offset = 0
<STX>sMN resetPreset<ETX>
<STX>sAN resetPreset<ETX>
Restart
--> Response OK
Complete reboot
<STX>sMN mSCreboot<ETX>
<STX>sAN mSCreboot<ETX>
Read out interface version
--> Response
<STX>sRN interfaceVersion<ETX>
<STX>sRA interfaceVersion B 001.004.019<ETX>
Read out firmware creation
date
--> Response
<STX>sRN firmwareBuildTime<ETX>
<STX>sRA firmwareBuildTime 14 2016/04/19
16:12:23<ETX>
Read out firmware verifica‐
tion key
--> Response
<STX>sRN firmwareVerification<ETX>
<STX>sRA firmwareVerification 13
1106-0684-9500-0000<ETX>
Reset to factory settings
--> Response OK
<STX>sMN resetParamAndReboot<ETX>
<STX>sAN resetParamAndReboot <[0, 1]><ETX>
3.7.3.2.5 Examples of command sequences
Switching on continuous, permanent distance value output
Table 18: Example: Switching on continuous, permanent distance value output
To Dx1000
<STX>sMN SetAccessMode 4 81BE23AA<ETX>
From Dx1000
<STX>sAN SetAccessMode 1<ETX>
To Dx1000
<STX>sWN rs422PeriodicOutputContent 1<ETX>
From Dx1000
<STX>sAN rs422PeriodicOutputContent<ETX>
To Dx1000
<STX>sMN mEEwriteall<ETX>
From Dx1000
<STX>sAN mEEwriteall 1<ETX>
PRODUCT DESCRIPTION 3
8019329/12TZ/2019-03-28 | SICK O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000
25
Subject to change without notice
