SICK DT1000

3. Tighten locking screws to fasten the additional filter:
PWR
In1/Q1
QA/Q2
Q3
Q4
In2
LNK
BUS
3
4
1
2
Disassembling additional filter
1. Unscrew locking screws:
PWR
In1/Q1
QA/Q2
Q3
Q4
In2
LNK
BUS
3
4
1
2
2. Insert a screwdriver with a thin bald under the snap hook into the recess in the
underside of the housing to loosen the snap hook:
MOUNTING 5
