SICK DT1000 User Manual

Product type DL1000 DT1000
Typical light spot size
W x H (distance)
5 mm x 20 mm (at 1 m)
20 mm x 20 mm (at 5 m)
35 mm x 25 mm (at 10 m)
150 mm x 50 mm (at 50 m)
290 mm x 80 mm (at 100 m)
570 mm x 140 mm (at 200 m)
4,200 mm x 920 mm(at 1,500 m)
5 mm x 20 mm (at 1 m)
20 mm x 20 mm (at 5 m)
20 mm x 20 mm (at 5 m)
20 mm x 20 mm (at 5 m)
20 mm x 20 mm (at 5 m)
20 mm x 20 mm (at 5 m)
Filter Rain and snow filter
Fog filter
Moving average distance value
Kalman filter
Moving average speed value
Maximum object tem‐
perature
n/a +1,400 °C
12
Additional function Selection of the relevant distance and signal level area, selection of
first or last echo in selected distance and signal level range
Average service life of
measurement laser
(at 25 °C)
100,000 h
1
With max. ambient light 100 kLux sunlight
2
On “diamond grade” reflective tape (DG983)
3
Dependent on reflector size and measurement cycle time
4
Dependent on remission and measurement cycle time
5
6% ... 90% remission
6
Data interface resolution
7
1 σ statistical error, ambient conditions constant, min. power-up delay of 15 minutes
8
At T = +23 °C and after min. power-up delay, about 15 minutes
9
From 100 m: ± 2 mm (20 ppm) per additional 100 m of measuring distance
10
Values apply for “Axial object tracking” measurement mode with factory settings (measurement cycle
time 4 ms, Kalman filter on, speed filter 10 cycles)
11
Values apply for the following settings: Rain and snow filter deactivated, distance average filter deacti‐
vated (filter depth 1 cycle)
12
For high-temperature applications (typically > 1,200 °C) when the the “Ambient light” warning or error
occurs: only with optional additional filter for high-temperature applications (part number 2088511).
11 TECHNICAL DATA
96
O P E R A T I N G I N S T R U C T I O N S | DT1000 and DL1000 8019329/12TZ/2019-03-28 | SICK
Subject to change without notice
