7.6.4 Diagnostics
Overview
T
he process data status bits can be used as input elements for the logic.
Important information
WARNING
Ineffectiveness of the protective device due to the use of non-safe diagnostic data for
safety-related applications
The dangerous state may not be stopped or not be stopped in a timely manner in the
event of non-compliance.
b
Use non-safe process data status bits for diagnostic purposes only.
Process data status bits of the modules
T
able 123: Process data status bits of the modules
Process data status
bit
s
Value Description
Voltage supply of out‐
puts
(for modules with
safety outputs only)
0 Voltage supply of the outputs is outside the specified range,
fault switch-off due to short-circuit to VCC or cross-circuit to
other outputs.
1 Voltage supply of the output is OK
Input data status 0 One or more input bits of the associated module have been
se
t to 0 because an error has been detected (e.g., cross-cir‐
cuit or communication error). I.e., the input bits may have
different values than would normally be the case during
error-free operation.
1 Inputs of the associated module are OK
Output data status 0 An error has been detected at one or more outputs of the
a
ssociated module (e.g., overload, short-circuit or communi‐
cation error). I.e., the outputs may have different values than
would normally be the case during error-free operation.
1 Outputs of the associated module are OK
Process data status bits of the individual inputs or outputs
T
able 124: Process data status bits of the individual inputs or outputs
Process data status
bit
s
Value Description
Fast shut off control 0 Error or timeout in fast shut-off logic
1 Fast shut-off logic is OK
Status Ix, Iy
Dual-c
hannel evalua‐
tion
0 Error at the inputs
The input value is 0, regardless of the level at the terminals.
1 Dual-channel evaluation of Ix/Iy input is OK
Status Ix 0 Error at the input
T
he input value is 0, regardless of the level at the terminals.
1 Input is OK
Status Qx
S
hort-circuit to High
0 Output voltage level is High instead of Low when the output
is “Off”. With test pulses, also in case of short-circuits to VCC
or cross-circuits to other outputs.
All safety outputs of the module are “Off”, regardless of the
logic result.
1 Output is OK
7 CONFIGURATION
106
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
