Table 139: Safety-related characteristic data - safety outputs (Q)
Safety outputs (Q)
Single-channel
1)
Dual channel
Without test
pulse
s
2) 3)
With test pulses Without test
pulses
2) 3)
With test pulses
Safety integrity
level (IEC 61508)
SIL 3 SIL 3 SIL 3 SIL 3
SIL claim limit
(IE
C 62061)
SILCL 3 SILCL 3 SILCL 3 SILCL 3
Category (ISO 13849-1)
With test
pulses on all
safety outputs
of a module
Category 4 Category 4
Without test
pulse
s on one
or more safety
outputs of a
module
Category 3 Category 3 Category 4 Category 4
Performance
level (ISO
13849-1)
PL e PL e PL e PL e
PFH
D
(h
-1
) 5 × 10
-9
0.5 × 10
-9
5 × 10
-9
0.5 × 10
-9
PFD
a
vg
30 × 10
-5
4 × 10
-5
30 × 10
-5
4 × 10
-5
MTTF
D
IS
O
13849-1
[years]
500 500 500 500
T
M
IS
O 13849-1
[years]
20 20 20 20
1)
If you are using single-channel safety outputs (Q) for a safety-related application, then a protected or
separ
ate cabling is required for these safety outputs in order to achieve the safety-related characteristics.
Reason: While short-circuits to the supply voltage or cross-circuits to other outputs can be detected, no
other option to switch-off the device exist.
2)
If you are using single-channel or dual-channel safety outputs (Q) without test pulses, then a protected or
separate cabling is required for these safety outputs in order to achieve the safety-related characteristics.
Reason: Short-circuits to the supply voltage or cross-circuits to other outputs are not detected in the
switched-on state without test pulses.
This also applies if an output is used for a non-safety related application. Reason: Even if an internal
hardware error is detected, the switch-off capability of the other safety outputs may be impaired by
reverse currents.
3)
If you are using single-channel/dual-channel safety outputs (Q) without test pulses for a safety-related
application, then one of the following measures is required in order to achieve the safety-related charac‐
teristics:
•
Restart the safety controller once a year.
•
Manually switch off all safety outputs simultaneously for min. 2 s once a year. The supply voltage to
the outputs must be within the operating range during this manual test.
General data
T
able 140: General data
Climatic conditions
Ambient operating temperature
At altitudes up to 2,000 m
above sea level
–25 °C … +55 °C
TECHNICAL DATA 13
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
127
Subject to change without notice
