SICK Flexi Compact User Manual

Components of
t
he calculation
Description Value [ms]
2. Logic a) Response time
of the main module
logic
2 × logic execution time
Take the value from the report in the
configuration software.
Delay due to logic application (e.g.
s
witch-on delay or switch-off delay
function block)
Take the value from the report in the
configuration software.
b) Response time of
t
he routing
For OUT3 output to the gateway only
Delay: 8 ms
c) Response time of
t
he fast shut off logic
No delay time 0
3. Outputs Response time of the
observed output in
the signal path
OUT1, OUT2, OUT3, OUT4 or OUT5
•
"OUT1 - Response time of safety
outputs (Q)", page 134
•
"OUT2 - Response time of test
outputs (X)", page 134
•
"OUT3 … OUT5 - Response
time for processing of outgoing
process data", page 134
Total
IN1 - Response time of safety capable inputs (I)
T
able 148: IN1 - Response time of safety capable inputs (I)
When relevant? Description Value [ms]
Always Input processing time 3
ON-OFF debounce filter is configured. Min. debounce filter time
T
ake the value from the report in the con‐
figuration software.
Input element is connected to a test
out
put (X).
Max. tolerated test pulse delay
Take the value from the report in the con‐
figuration software.
Input element is connected to a test
out
put (X).
•
F
or safety sensors with a test input or
Flexi Loop: test pulse frequency of the
test output
•
For safety pressure mats: the longer
test pulse frequency of the two test
outputs
•
For electro-mechanical switch/safety
switch (EMSS): test pulse duration of
the test output
Total
IN3 … IN5 - Response time for processing of incoming process data
T
able 149: IN3 … IN5 - Response time for processing of incoming process data
When relevant? Description Value [ms]
IN3 When using a gateway. 2 × internal update interval (4 ms) - 2 ms
= 6 ms
IN4 When using Modbus® TCP
or SL
MP.
2 × internal update interval (20 ms) -
2 ms
= 38 ms
TECHNICAL DATA 13
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
133
Subject to change without notice
