SICK Flexi Compact - Dimensional drawings

13.4 Dimensional drawings
48,2
46,2 85,5
89,6
64,4
78,4
124,7
128,3
120,7
Figure 52: Dimensional drawing CPUc1
48,2
46,2 85,5
89,6
64,4
78,4
124,7 128,3 120,7
Figure 53: Dimensional drawing CPUc2
13 T
ECHNICAL DATA
146
