Synchronization time
T
he synchronization time is the amount of time for which the two inputs are allowed to
have different values.
Fixed value: 500 ms in accordance with EN 574
Sequence monitoring
T
he Enable output is set to 1 if both inputs were inactive at the same time for at least
the logic execution time before being activated.
If the Enable output = 1 and then at least one input becomes inactive, then the Enable
output = 0.
Complementary information
Dif
ferent propagation times of the input signals can lead to a lengthening or shortening
of the synchronization time.
Further topics
•
"Configuration options for input elements", page 46
7.6.2.4.2 Two hand control (4 inputs) V1
Overview
T
his function block provides the logic for monitoring the inputs of a two-hand control
device. The category 1 (Type IIIA) or category 4 (Type IIIC) according to EN 574 depends
on the wiring and parameterization.
Principle of operation
Table 74: Inputs
Input Description
1A (NO)
1B (N
C)
2A (NO)
2B (NC)
Data type: Boolean
•
In
put pair 1: 1A (NO), 1B (NC)
•
Input pair 2: 2A (NO), 2B (NC)
Table 75: Outputs
Output Description
Enable Data type: Boolean
•
0 = no
t enabled
•
1 = enabled
The Enable out
put is set to 1 if the following conditions are met:
°
Bo
th input pairs are inactive at the same time for at least the
duration of the logic execution time
°
Both input pairs are then active
Status input pair 1 Data type: Boolean
•
0 = Er
ror
Input pair has not gone into a complementary status within the
discr
epancy time.
•
1 = N
o error or unknown
Status input pair 2
Synchronization status Data type: Boolean
•
0 = Er
ror
Synchronization time exceeded.
•
1 = N
o error or unknown
7 CONFIGURATION
74
O P E R A T I N G I N S T R U C T I O N S | Flexi Compact 8024589/2020-11-10 | SICK
Subject to change without notice
