SICK Flexi Compact User Manual

Applies to EDM operating
mode
Error Reset condition
Turn-on
monit
oring
Turn-on moni‐
toring and
turn-off moni‐
toring
No Yes After the C
ontrol input input = 0,
the EDM feedback signal input
does not switch to 1 within the
configured feedback delay time.
The EDM feedback signal input = 1
for the duration of the config‐
ured feedback time, and the
Control input input must be = 0 at
the latest by expiry of the feed‐
back delay time.
Sequence/timing diagram
Figure 36: Sequence/timing diagram
Figure 37: Sequence/timing diagram
CONFIGURATION 7
