7.6.2.6.5 Multi enable V1
Overview
Eac
h input of the function block is separately linked to the Release input via AND logic. If
Input n and the Release input = 1, then Output n = 1.
Principle of operation
Table 103: Inputs
Input Description
Input 1 Data type: Boolean
Input 2 … Input 8
(opt
ional)
Release Data type: Boolean
Table 104: Outputs
Output Description
Output 1 … Output 8 Data type: Boolean
If In
put n and the Release input = 1, then Output n = 1
Table 105: Parameter
Parameter Description
Available inputs 1 … 8
Inverted You can individually invert any visible input. At an inverted input, a 0
works internally in the same way as a 1 and vice versa.
7.6.2.6.6 Multi latch V1
Overview
D
epending on the Set input, the status of up to 8 inputs can be forwarded or saved at
the respective outputs.
Principle of operation
Table 106: Inputs
Input Description
Input 1 Data type: Boolean
Input 2 … Input 8
(opt
ional)
Set Data type: Boolean
D
epending on the Inversion parameter, a rising or a falling signal edge
saves the current status of inputs 1 ... 8 at the Set input. The function
block also saves the statuses of the inputs when the Set input is
already 1 in the first logic cycle.
Table 107: Outputs
Output Description
Output 1 … Output 8 Data type: Boolean
If t
he Set input = 0, the function block forwards the status of the
inputs to the corresponding outputs unchanged.
If the Set input changes from 0 1, the function block saves the
current status of inputs 1 … 8. The function block outputs the saved
status to the outputs as long as the Set input = 1. The status change
of inputs 1 … 8 does not influence the outputs as long as the Set
input = 1.
CONFIGURATION 7
8024589/2020-11-10 | SICK O P E R A T I N G I N S T R U C T I O N S | Flexi Compact
91
Subject to change without notice
