4.6.2
Ball valve
The ball valve serves for safe separation of the sender/receiver units from the process and
is required when the sender/receiver units are to be dismounted during the process. SICK
recommends using a ball valve.
Ball valves for various flange connections (Cl150, CL300, PN25 DN50) and temperature
ranges) are available.
Table 6 Ball valve according to ANSI
Table 7 Ball valve according to DIN
NOTICE:
Observe the diagrams on  p. 79, §7.3.
Component Connection Material (ASTM) Gas temperature range
Standard temperature
Ball valve CL150 2" SS CL150 2" Stainless steel 1.4408
(CF08M)
-46...+200°C
(-50...+392°F)
Ball valve CL300 2" SS CL300 2" Stainless steel 1.4408
(CF08M)
-46...+200°C
(-50...+392°F)
Low temperature
Ball valve CL150 2" SS CL150 2" Stainless steel 1.4408
(CF08M)
-196...+200°C
(-320...+392°F)
Ball valve CL300 2" SS CL300 2" Stainless steel 1.4408
(CF08M)
-196...+200°C
(-320...+392°F)
High temperature
Ball valve CL150 2" SS CL150 2" Stainless steel 1.4408
(CF08M)
-50...+400°C
(-58...+752°F)
Ball valve CL300 2" SS CL300 2" Stainless steel 1.4408
(CF08M)
-50...+400°C
(-58...+752°F)
Component Connection Material (ASTM) Gas temperature range
Standard temperature
Ball valve PN16 DN50 SS PN16 DN50 Stainless steel 1.4408
(CF08M)
-46...+200°C
(-50...+392°F)
Low temperature
Ball valve Stainless steel 1.4408
(CF08M)
-196...+200°C
(-320...+392°F)
High temperature
Ball valve PN40 DN50 PN40 DN50 Stainless steel 1.4408
(CF08M)
-50...+400°C
(-58...+752°F)
