22 FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V1-0/2020-05 · © SICK Engineering GmbH
Product description
3. 2
Sender/receiver units
Cross-duct
Fig. 5 F1F-S (Master and slave shown as examples)
1 Pressure compensation element 6 Retraction nozzle
2 Electronics unit 7 Duct probe
3 T-connector 8 Sensor contour
4 TNC connector (connection for Slave) 9 Transducer
5 Self-cutting ring 10 TNC connector (connection for Master)
1 7
8
6
4
532
Sensor length
9
8
65
9
7 910
