Installation
FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V1-0/2020-05 · © SICK Engineering GmbH 31
4.3
Fitting the spool piece (option)
The spool piece must be mounted in the pipeline so that the arrow marking on it corre-
sponds to the flow direction.
The flow is output by the measuring system as a positive value when master and slave of
the sender/receiver units for the cross-duct versions are installed according to Operating
Instructions FLOWSIC100 Flare, Figure 2.
Required fitting work
Position the spool piece at the desired section of the pipeline using the hoist.
After attaching the flange bolts, but before tightening, check the correct seating and
alignment of the flange seal.
Align the spool piece so that the offset between inlet pipe, spool piece and outlet pipe is
minimized.
Insert the remaining fixing screws and tighten the nuts crosswise. The applied torque
must not be lower than specified in the project planning.
Install the pressure measurement line between the pressure tapping point (option) and
the pressure sensor (option).
Perform a leak tightness check with suitable means after completion of the installation
work,

p. 58, §4.8.4.
WARNING: Hazard due to size and mass of the spool piece
Observe the transport information on

p. 27, §3.5.2 !
