Installation
FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V1-0/2020-05 · © SICK Engineering GmbH 61
4.1 1
Fitting the weatherproof cover for the sender/receiver units
The weatherproof cover (Order No. 2105581) serves to shield the electronics of the
sender/receiver units from sunlight and weather influences.
4.11.1 Overview
Fig. 38 Weather protection overview
1
2
6
3
5
2
4
4 5
1 Holder
2 Safety splints
3 Weatherproof cover
4 Washers
5 Hexagon nuts
6 Round steel bow
