Technical data
FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V1-0/2020-05 · © SICK Engineering GmbH 75
7.1.2
F1F-M
7.1.3 F1F-H
Table 11 Technical data F1F-M
Measuring conditions
Operating pressure:
1)
CL150 device flange: 20 bar (g)
PN25 device flange (optional): 20 bar (g)
CL300 device flange (optional). 20 bar (g)
Gas temperature –196 °C ... +280 °C
Ex approvals
IECEx Ex db [ia Ga] IIC T6 Ga/Gb
Ex db [ia Ga] IIB T4 Ga/Gb
Ex db [ia Ga] IIA T4 Ga/Gb
ATEX II 1/2G Ex db [ia Ga] IIC T6 Ga/Gb
II 1/2G Ex db [ia Ga] IIC/IIB/IIA T4 Ga/Gb
NEC/CEC (US/CA) Cl I, Div1 Group C, D T4;
Cl I, Zone 1, Ex/AEx d [ia] IIB, T4
Cl I, Div2 Group C, D T4;
Cl I, Zone 2, Ex/AEx nA [ia] IIB, T4
Installation
Weight ≤ 12 kg (sensor pair)
1)
Temperature dependent, details see  p. 79, §7.3  »Derating of pressure resistance«
Table 12 Technical data F1F-H
Measuring conditions
Operating pressure:
1)
CL150 device flange:
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
PN25 device flange (optional):
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
CL300 device flange (optional):
ATEX/IECEx: 20 bar(g)
CSA: 16 bar(g)
Gas temperature –70 °C ... +280 °C
Ex approvals
IECEx Ex db IIC T6/T4 Gb
Ex db eb IIC T6/T4 Gb
ATEX II 2G Ex db IIC T6/T4 Gb
II 2G Ex db eb IIC T6/T4 Gb
NEC/CEC (US/CA) Cl I, Div1 Group B, C, D T4
Cl I, Zone 1, Ex/AEx d IIB + H2, T4
Cl I, Div2 Group A, B, C, D T4
Cl 1, Zone 2, Ex/AEx nA IIC, T4
Installation
Weight ≤ 14 kg (sensor pair)
1)
Temperature dependent, details see  p. 79, §7.3  »Derating of pressure resistance«
