SICK FLOWSIC100 Flare Addendum To Operating Instructions

Installation
FLOWSIC100 Flare · Addendum to Operating Instructions · 8025365/V1-0/2020-05 · © SICK Engineering GmbH 59
4 Close the ball valve.
Fig. 36 Cap nut
NOTICE:
The ball valve must close without resistance.
If this is not possible:
▸ Make sure the sender/receiver unit has been pulled back completely.
NOTICE:
Do not use force when the sender/receiver unit cannot be pulled back.
▸ Tighten the pipe screw fitting again with a torque of 150 Nm.
▸ Contact SICK Service.
WARNING: Hazardous gas (possibly explosive or toxic)
Consider the gas trapped in the retraction nozzle,  p. 12, §2.4.
1 Cap nut (self-cutting ring fitting)
2 Pipe screw fitting
1
2
