SICK GLS611 - 11 Technical Data; Features

11 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/GLS6
Please note: This documentation may contain further technical data.
11.1
Features
Focus Adjustable focus, manual focus adjustment tool in combination
with the LEDs on the device (first display level)
Sensor resolution 1.2 Mpx (1,280 px x 960 px)
Integrated illumination
unit
8 LEDs:
•
4 LEDs with visible amber light (λ = 617 nm ± 50 nm)
•
4 LEDs with visible blue light (λ = 470 nm ± 15 nm)
Feedback LED (spot in field
of view)
1 LED:
•
Visible green light (λ = 525 nm ± 15 nm)
•
Visible red light (λ = 635 nm ± 15 nm)
LED alignment aid (2
points in the field of view)
2 LEDs, can be deactivated:
Visible red light (λ = 630 nm ± 15 nm)
LED risk group Integrated illumination unit:
Risk group 1 (low risk) according to IEC 62471-1: 2006-07 / EN
62471-1: 2008-09 including EU Directive 2006/25 / EC (DIN EN
62471:2009-03 is identical to EN 62471:2008-09).
Radiance
•
L
B
1)
: < 10 x 10
3
W/(m
2
sr) within 100 s; at distance ≥ 200 mm
•
L
R
2)
: <2.2 x 10
6
W/(m
2
sr) within 10 s; at distance ≥200 mm
Distance-dependent hazard value
•
Risk group 0 (no risk) based on L
B
1)
: < 100 W/(m
2
sr) within
10,000 s; at a distance of > 2.0 m.
Feedback LED, LED alignment aid and status LEDs:
Risk group 0 (no risk) according to IEC 62471-1: 2006-07 / EN
62471-1: 2008-09 including EU Directive 2006/25 / EC (DIN EN
62471:2009-03 is identical to EN 62471:2008-09).
MTBF of LEDs Integrated illumination unit, feedback LED and LED alignment
aid:
75,000 h, at 25 °C ambient operating temperature
Time-of-flight sensor 1 laser (distance measurement in configuration mode):
Invisible infrared light (wavelength 940 nm, max. output power
≤ 17.5 mW, pulse length ≤ 3.7 ns)
Laser class Time-of-flight sensor:
Laser class 1 according to EN/IEC 60825-1:2014. Complies with
21 CFR 1040.10 except for conformance with IEC 60825-1 Ed.
3.0 as described in “Laser Notice 56” dated May 8, 2019.
Scanning frequency 1.2 Mpx: maximum 40 Hz at full resolution
Code resolution 1D code: ≥0.05 mm
2D code: ≥0.1 mm
The code resolution depends on the working distance.
Valid for 1D codes and 2D codes with good print quality.
