SICK GLS611 - Mechanics;Electronics; Performance

Working range 50 mm ... 300 mm
Lens Focal length: 6 mm
Overrun speed ≤5 m/s
1)
L
B
= H
azard from blue light.
2)
L
R
= H
azard to the retina of the eye due to heating.
11.2 Mechanics/electronics
Electrical connection 1 cable (length: 0.35 m) with male connector, M12, 17-pin, A-
coded
Ma
ximum length: 30 m
Maximum length when used as a serial interface: 15 m
1 cable (length: 0.25 m) with female connector, M12, 4-pin, D-
coded
Supply voltage V
S
12 ... 24 V DC, ±15%
V
oltage source in accordance with ES1 and PS2 (EN 62368-1) or
SELV and LPS (EN 60950-1).
Power consumption Operation: 3.5 W typical
1)
Ma
ximum 16 W (peak) with typical loading of the 3 digital outputs
with 50 mA each and 27.6 V DC supply voltage
Current consumption Max. 1.5 A (peak) at 10.2 V DC
Housing material Die cast aluminum, plastic
Housing color Light blue (RAL 5012), black
Viewing window material Plastic (PMMA), 2 mm thick
Enclosure rating IP 54 (EN 60529, EN 60529 / A2)
2)
Protection class III
Electrical safety EN 62368-1 (2014-08)
Weight 165 g, including connecting cables
Dimensions (L x W x H) 50 mm x 40.3 mm x 29.6 mm
3)
1)
For digital outputs without load.
2)
Prerequisite: The male connectors and female connectors of both connecting cables are connected and
scr
ewed together at the device being connected.
3)
see "Setup and dimensions", page 14.
11.3 Performance
Readable code structures 1D, 2D, stacked codes, DPM
1D code types (bar code) GS1-128 / EAN 128, UPC / GTIN / EAN, 2/5 interleaved, Pharma‐
code
, GS1 DataBar, Code 39, Code 128, Codabar, Code 32, Code
93, Plessey Code, MSI/Plessey, Telepen, postal codes
2D code types Data Matrix ECC200, GS1 Data Matrix, PDF417, PDF417 Trun‐
cated, QR-Code, MaxiCode
Code qualification On the basis of ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 15416,
ISO/IEC 18004
No. of codes per reading
int
erval
1 ... 50 (auto-discriminating)
No. of characters per read‐
ing interval
Max. 500 (for multiplexer function in CAN network operation)
Evaluation time > 60 μs
Shutter time 60 μs ... 6,000 μs
TECHNICAL DATA 11
