SICK GLS611 - Interfaces

Automatic parameter
switching
Integrated
11.4 Interfaces
Ethernet Protocol:
•
TCP/IP
•
EtherNet/IP
•
Modbus® TCP
Function: host (data output of the read result)
Function: Aux (service)
1)
Data transmission rate: 10/100 Mbit/s
Services: DHCP, NTP, HTTP, mDNS, DNS-SD, DNS, HTTPS.
MAC address (device-specific), see type label
Serial RS-232 Function: host (data output of the read result)
Data transmission rate: 0.3 kBd ... 115.2 kBd
CAN Protocol:
•
A connection in a CANopen-based environment is possible. For
additional support, please contact SICK customer service.
•
SICK CAN sensor network CSN (master/slave, multi‐
plexer/server)
Function: host (data output of the read result)
Data transmission rate: 20 kBit/s ... 1 MBit/s
Bus length: maximum 30 m
PROFINET (line topology) Function: host (data output of read result), PROFINET Single Port
Data transmission rate: 10/100 Mbit/s
Function blocks for various PLC manufacturers are available online
at: www.sick.com/Lector61x
Digital inputs Type: 2 x physical, switching (“Sensor 1”, “Sensor 2”)
V
in
2)
= max. 27.6 V, I
in
3)
= max. 5 mA
Opto-decoupled, not reverse polarity protected regarding supply
voltage
Debounce time: adjustable
4)
Encoder frequency: max. 300 Hz
Digital outputs Type: 3 x physical, switching (“Result 1” ... “Result 3”)
V
out
5)
= V
S
6)
– 1.5 V, I
out
7)
≤ 50 mA (typical)
Short-circuit protected, not electrically isolated from the supply
voltage V
s
Reading pulse Digital inputs, free, serial interface, Ethernet, CAN, auto pulse or
presentation mode
Optical indicators 6 status LEDs on the side of the device
2 LED alignment aids on the front side of the device
1 feedback LED (green and red) as a light spot on the code
Operator interfaces Web server
Configuration software
(parameterization)
SOPAS ET configuration software, web server, CoLa commands
(telegrams), fieldbus controller (PLC) with additional support by
SICK function blocks
Data storage and retrieval Image and data storage via internal memory and external FTP
11 TECHNICAL DATA
