CommentBinaryRangeAttributeValue tagContainer tag
figured value in the Ethernet
Result output dialog.
For a polygon with two corners
(single edge) the estimated
corner positions are the inter-
section between the found
edge and the left and right
borders of the search region.
The search region is defined by
the user drawn edge and the
position search parameter. See
also Operating Instructions for
Inspector PIM60 about Single
edge tool.
Polygon corner coordinate.
“pixels” or “mm” depending on
REAL
c
REALcoordUnitY
attribute “coordUnit” or con-
figured value in the Ethernet
Result output dialog.
For a polygon with two corners
(single edge) the estimated
corner positions are the inter-
section between the found
edge and the left and right
borders of the search region.
The search region is defined by
the user drawn edge and the
position search parameter. See
also Operating Instructions for
Inspector PIM60 about Single
edge tool.
Name attribute required if
more than one Blob tool exists.
any stringnameBLOB
The name refers to the Blob
tool's name in the tool tab
Index of found blob according
to current blob sorting order.
Index 0 is the first blob
[0, 15]index
Blob center of gravity (x posi-
tion). “pixels” or “mm” depend-
ing on attribute “coordUnit”
REALcoordUnitX
Blob center of gravity (y posi-
tion). “pixels” or “mm” depend-
ing on attribute “coordUnit”
REALcoordUnitY
Number of found blobs.USINTFOUND_
BLOBS
d
The lower threshold of the Blob
tool's intensity after applying
ambient light compensation.
USINTLIVE_
THRESHOLD_
LOW
d
The upper threshold of the
Blob tool's intensity after apply-
USINTLIVE_
THRESHOLD_
43
