10 Technical data
10.1 Optics and Illumination
Type PLOC2D
Focus PLOC2D-2000:
Fixed focus and aperture on the lens.
InspectorP65x:
Manual adjustment of the focus and aperture on the optional lens unit.
InspectorP63x:
Compact C-mount lenses: Fixed aperture, manual sharpness setting on the
lens.
C-mount lenses: Manual sharpness and aperture setting on the lens.
S-mount lenses: Fixed aperture, working distances can be implemented
using distance ring, manual sharpness setting using focus screw.
InspectorP62x:
Electric adjustment of the focus on the lens.
InspectorP611:
Manual adjustment of the focus on the lens (with the included tool)
Illumination for
field of view
Optional e.g., variants of the VI83I integrable illumination unit: 11 x LED,
visible light. White (λ = 6,000 ± 500 K) Blue (λ = 455 ± 20 nm) Red (λ = 620
± 30 nm).
InspectorP62x 4 LEDs (2 on the left, 2 on the right)
Light color combination, type-dependent: Visi‐
ble red light (λ = 617 nm ± 15 nm) Visible blue
light (λ = 470 nm ± 15 nm) Infrared light (λ =
850 nm ± 25 nm)
InspectorP611 8 LEDs (4 amber, 4 blue)
Light color combination, optional: Visible
amber light (λ = 617 nm ± 50 nm) Visible blue
light (λ = 470 nm ± 15 nm)
Feedback LED
(spot in field of
view)
InspectorP62x/611 or optional e.g., variants of the VI83I integrable illumi‐
nation unit:
1 x LED, visible green light (λ = 525 ± 15 nm).
LED risk group of
illumination unit
Risk group 1 (low risk) according to IEC 62471-1: 2006-07/EN 62471-1:
2008-09.
“Blue - Narrow + Feedback LED” option (PLOC2D-2000)
•
Risk group 2 (moderate risk) according to IEC 62471-1: 2006-07/EN
62471-1: 2008-09 due to exposure to blue light.
Aiming laser (field
of view)
Visible light. Red (λ = 630 nm ... 680 nm), can be disengaged
InspectorP611: Visible light. Red (λ = 630 nm ± 15 nm), can be disengaged
Laser class 1, complies with 21 CFR 1040.10 except for the tolerance according to
“Laser Notice No. 50” from June 24, 2007 (IEC 60825-1:2014, EN60825-
1:2014).
10.2 Performance
Type PLOC2D
Working distance See "Field of view diagrams", page 16
Image sensor res‐
olution
InspectorP65x: 4.2 MP
InspectorP63x: 1.3 MP (InspectorP631), 1.9 MP (InspectorP632)
InspectorP62x: 1.3 MP
InspectorP611: 1.2 MP
10 TECHNICAL DATA
72
