SICK PLOC2D 4.1 - Interfaces; Mechanics and Electronics

Type PLOC2D
Image sensor
type
InspectorP65x/62x/611: CMOS matrix sensor, gray scale
InspectorP63x: Monochrome
Image memory MicroSD memory card.
InspectorP611: Internal memory
10.3 Interfaces
Type PLOC2D
Ethernet TCP/IP
Function: EtherNet/IP, UDP, PROFINET
Data transmission rate:
•
InspectorP65x + P63x: 10 Mbit/s ... 1,000 Mbit/s
•
InspectorP62x/611: 10 Mbit/s ... 100 Mbit/s
Protocol: FTP, HTTP
Operator interfa‐
ces
Web server
10.4 Mechanics and electronics
Type PLOC2D
Optical indicators InspectorP65x: 10 x RGB status LEDs, 10 x bar graph, 1 x green feedback
spot
InspectorP63x: 5 x RGB LEDs: status indicators, 1 x LED: feedback LED,
green, 5 x RGB LEDs: bar graph, blue
InspectorP62x: 5 x status LEDs, 10 x LED bar graphs, 1 x green feedback
spot
InspectorP611: 6 x status LEDs, 8 x illumination LEDs, 1 x green feedback
spot
Acoustic indica‐
tors
1 x beeper for signaling events, can be deactivated
Supply voltage 24 V DC ± 20%
InspectorP62x: 12 V DC ... 24 V DC, ± 20 %
InspectorP611: 12 V DC ... 24 V DC, ± 15 %
Current consump‐
tion
InspectorP65x: Max. 2.0 A (with switching outputs)
InspectorP63x: Max. 1.5 A (with switching outputs)
Power consump‐
tion
InspectorP65x: Typically 20 W (for switching outputs without load)
InspectorP63x: 10 W (for switching outputs without load)
InspectorP62x: Typically 4 W
InspectorP611: Typically 3.5 W
Weight InspectorP65x: 635 g excluding optics
InspectorP63x: 430 g excluding optics
InspectorP62x: 170 g
InspectorP611: 165 g
Material
Housing
Aluminum die cast
InspectorP611: Zinc die cast
Material
Viewing window
Glass or plastic (PMMA), 2 mm thick, with scratch-proof coating.
Electrical protec‐
tion class
III, in accordance with DIN EN 60950-1: 2014-08
Enclosure rating InspectorP65x + P62x: IP65
InspectorP63x: IP67
InspectorP611: IP54
TECHNICAL DATA 10
