Result sorting
By default results are sorted by score. For applications where the parts are aligned in
an ordered structure and the order of results are important, select Lanes in the Order
list.
To change the Result sorting or adjust the settings a successful locate of the job is
required. The settings apply to all jobs using the work plane referenced in the Result
sorting heading.
The lane positions are automatically adjusted to the first found part. All parts found in a
specific lane are then sorted within the lane in the sorting direction.
To adjust the width and rotation of lanes, drag the Lane width and Lane angle sliders or
use the lane tool in the image view.
To use the lane tool
•
Click
.
✓
The lane tool controls are visible in the image view.
To adjust the width of lanes
•
Move the pointer to a lane border. When the pointer becomes a , drag the
pointer to adjust the lane widths.
To adjust the rotation of lanes
•
Move the pointer over the lanes. When the pointer becomes a , drag the pointer
to rotate the lanes.
To change the lane order
•
Click the lane order buttons to change the lane order.
•
Click to order lanes from left to right and report results within lanes from top to
bottom.
•
Click to order lanes from left to right and report results within lanes from
bottom to top.
•
Click to order lanes from right to left and report results within lanes from top to
bottom.
•
Click
to order lanes from right to left and report results within lanes from
bottom to top.
•
Click to order lanes from top to bottom and report results within lanes from
right to left.
•
Click to order lanes from top to bottom and report results within lanes from left
to right.
•
Click to order lanes from bottom to top and report results within lanes from left
to right.
•
Click to order lanes from bottom to top and report results within lanes from
right to left.
•
Click to zoom out.
•
Click an arrow in a lane to change the order in that specific lane.
7.2.6 System settings
Use the System tab to adjust system settings and monitor the system log.
