Operating Instructions
UE403
8010854/WP71/2012-11-28 © SICK AG • Industrial Safety Systems • Germany • All rights reserved v
Subject to change without notice
Update
Checklist for the manufacturer
Checklist for the manufacturer/installer for the installation of electro-
sensitive protective equipment (ESPE)
Details about the points listed below must be present at least during initial commissioning — they are, however,
dependent on the respective application, the specifications of which are to be controlled by the manufacturer/installer.
This checklist should be retained and kept with the machine documentation to serve as reference during recurring
tests.
1. Have the safety rules and regulations been observed in compliance with the directives/standards applicable to
the machine?
Yes No
2. Are the applied directives and standards listed in the declaration of conformity? Yes No
3. Does the protective device fulfil the required PL/SILCL and PFHd according to EN ISO 13849-1/EN 62061 and
the type according to EN 61496-1?
Yes No
4. Is the access to the hazardous area/hazardous point only possible through the protective field of the ESPE? Yes No
5. Have appropriate measures been taken to prevent (mechanical protection) or monitor unprotected presence in
the hazardous area when protecting a hazardous area/hazardous point and have these been secured against
removal?
Yes No
6. Are additional mechanical protective measures fitted and secured against manipulation which prevent reaching
under, over or around the ESPE?
Yes No
7. Has the maximum stopping and/or stopping/run-down time of the machine been measured, specified and
documented (at the machine and/or in the machine documentation)?
Yes No
8. Has the ESPE been mounted such that the required safety distance from the nearest hazardous point has been
achieved?
Yes No
9. Are the ESPE devices correctly mounted and secured against manipulation after adjustment? Yes No
10. Are the required protective measures against electric shock in effect (protection class)? Yes No
11. Is the control switch for resetting the protective device (ESPE) or restarting the machine present and correctly
installed?
Yes No
12. Are the outputs of the ESPE (OSSDs, AS-Interface Safety at Work) integrated in compliance with the required
PL/SILCL according to EN ISO 13849-1/EN 62061 and does the integration comply with the circuit diagrams?
Yes No
13. Has the protective function been checked in compliance with the test notes of this documentation? Yes No
14. Are the given protective functions effective at every setting of the operating mode selector switch? Yes No
15. Are the switching elements activated by the ESPE, e.g. contactors, valves, monitored? Yes No
16. Is the ESPE effective over the entire period of the dangerous state? Yes No
17. Once initiated, will a dangerous state be stopped when switching the ESPE on or off and when changing the
operating mode, or when switching to another protective device?
Yes No
18. Has an information label for the daily check been attached so that it is easily visible for the operator? Yes No
This checklist does not replace the initial commissioning, nor the regular inspection by qualified safety personnel.
