Step by Step
Administration optiPoint 410 entry
32
optiPoint 410 entry
After integrating the optiPoint 410 entry into your net-
work successfully Æ page 16, you can make all other
settings through the "Web-based Management Tool"
Æ page 42.
Entering the administration area
All configuration and diagnostic operations are protect-
ed against illegal accesses by the Administrator pass-
word.
edg Press keys simultaneously to enter "administration area".
o Enter admin password
(default: 123456).
r Terminate the operation.
You are now in the administration area (all LEDs flash).
View settings
You can make the system display the important settings
of your optiPoint 410 entry.
Making changes in the administration area (see above).
Press the 2
nd
function key from the top.
o Enter the 2-digit code (Table Æ page 103) for the de-
sired function.
r Confirm the entry.
The settings are displayed through different illumina-
tions of the LEDs. The table on Æ page 100 describes
the meaning of the LEDs.
If you are in the administration area, you cannot
reach the optiPoint 410 entry ("offline").
