Siemens 6RA8085-6DS22

Connecting
6.6 Line reactors
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
147
Table 6- 5 3-phase line reactors, rated voltage = 480 V AC, uk = 4%
Article number
Rated current
Inductance
Copper
losses
Total
losses
SCCR
Weight
Rated insulation
voltage
6RX1800-4FK00
13 A AC
2.779 mH
27.4 W
39.2 W
2.0 kA (20 ms)
2.9 kg
600 V
6RX1800-4FK01 25 A AC 1.389 mH 34.8 W 57.8 W 5.0 kA (20 ms) 6.0 kg 600 V
6RX1800-4FK02
51 A AC
0.695 mH
42.3 W
77.2 W
6.5 kA (100 ms)
11.8 kg
600 V
6RX1800-4FK03
76 A AC
0.463 mH
56.3 W
118.0 W
9.0 kA (100 ms)
16.3 kg
600 V
6RX1800-4FK04
106 A AC
0.333 mH
68.8 W
152.9 W
15 kA (100 ms)
22.3 kg
600 V
6RX1800-4FK05
174 A AC
0.202 mH
204.6 W
255.6 W
15 kA (100 ms)
26.0 kg
600 V
6RX1800-4FK06
232 A AC
0.152 mH
178.3 W
231.4 W
20 kA (100 ms)
37.8 kg
600 V
6RX1800-4FK07
332 A AC
0.106 mH
193.7 W
261.5 W
24 kA (100 ms)
56.1 kg
600 V
6RX1800-4FK08
374 A AC
0.094 mH
189.1 W
279.2 W
24 kA (100 ms)
56.8 kg
600 V
6RX1800-4FK10
498 A AC
0.071 mH
313.8 W
396.9 W
35 kA (200 ms)
78.1 kg
1000 V
6RX1800-4FK11
664 A AC
0.053 mH
255.6 W
360.8 W
75 kA (200 ms)
96.6 kg
1000 V
6RX1800-4FK12
706 A AC
0.050 mH
293.9 W
404.1 W
75 kA (200 ms)
96.6 kg
1000 V
6RX1800-4FK13
913 A AC
0.039 mH
375.6 W
558.6 W
75 kA (200 ms)
114.5 kg
1000 V
6RX1800-4FK14
996 A AC
0.035 mH
332.7 W
532.8 W
75 kA (200 ms)
127.8 kg
1000 V
6RX1800-4FK15
1328 A AC
0.027 mH
320.4 W
573.7 W
75 kA (200 ms)
177.6 kg
1000 V
6RX1800-4FK16
1660 A AC
0.021 mH
436.5 W
819.0 W
75 kA (200 ms)
161.0 kg
1000 V
6RX1800-4FK17
1326 A AC
0.019 mH
464.7 W
819.9 W
75 kA (200 ms)
164.2 kg
1000 V
6RX1800-4FK18
2324 A AC
0.015 mH
671.8 W
1056.7 W
75 kA (200 ms)
258.2 kg
1000 V
Table 6- 6 3-phase line reactors, rated voltage = 575 V AC, uk = 4%
Article number
Rated current
Inductance
Copper
losses
Total
losses
SCCR
Weight
Rated insulation
voltage
6RX1800-4GK00
51 A AC
0.832 mH
56.8 W
109.7 W
6.5 kA (100 ms)
13.6 kg
600 V
6RX1800-4GK01
106 A AC
0.399 mH
65.6 W
156.7 W
15 kA (100 ms)
26.4 kg
600 V
6RX1800-4GK02
174 A AC
0.243 mH
150.0 W
200.5 W
15 kA (100 ms)
34.5 kg
600 V
6RX1800-4GK03
332 A AC
0.127 mH
252.1 W
327.3 W
24 kA (200 ms)
63.1 kg
600 V
6RX1800-4GK04 498 A AC 0.085 mH 330.3 W 427.5 W 35 kA (200 ms) 86.0 kg 1000 V
6RX1800-4GK05
598 A AC
0.071 mH
339.6 W
455.5 W
55 kA (200 ms)
89.8 kg
1000 V
6RX1800-4GK06 631 A AC 0.067 mH 322.8 W 441.1 W 55 kA (200 ms) 95.7 kg 1000 V
6RX1800-4GK07
664 A AC
0.064 mH
380.7 W
547.2 W
75 kA (200 ms)
108.4 kg
1000 V
6RX1800-4GK08
706 A AC
0.060 mH
392.7 W
564.5 W
75 kA (200 ms)
120.6 kg
1000 V
6RX1800-4GK10
830 A AC
0.051 mH
308.1 W
498.3 W
75 kA (200 ms)
134.8 kg
1000 V
6RX1800-4GK11
913 A AC
0.046 mH
320.7 W
515.9 W
75 kA (200 ms)
143.9 kg
1000 V
6RX1800-4GK12
1245 A AC
0.034 mH
371.4 W
605.4 W
75 kA (200 ms)
206.1 kg
1000 V
6RX1800-4GK13
1328 A AC
0.032 mH
503.1 W
812.4 W
75 kA (200 ms)
160.9 kg
1000 V
6RX1800-4GK14
1660 A AC
0.025 mH
631.3 W
993.1 W
75 kA (200 ms)
202.0 kg
1000 V
6RX1800-4GK15
1826 A AC
0.023 mH
614.7 W
1006.9 W
75 kA (200 ms)
212.1 kg
1000 V
6RX1800-4GK16
2158 A AC
0.020 mH
534.6 W
1073.7 W
75 kA (200 ms)
303.0 kg
1000 V
6RX1800-4GK17
2324 A AC
0.018 mH
556.2 W
1110.0 W
75 kA (200 ms)
321.6 kg
1000 V
