Connecting
6.6 Line reactors
SINAMICS DCM DC Converter
148 Operating Instructions, 12/2018, A5E34763375A
Table 6- 7 3-phase line reactors, rated voltage = 690 V AC, uk = 4%
Article number
Rated current
Inductance
Copper
losses
Total
losses
SCCR
Weight
Rated insulation
voltage
6RX1800-4KK00
598 A AC
0.085 mH
388.2 W
562.1 W
55 kA (200 ms)
108.9 kg
1000 V
6RX1800-4KK01 631 A AC 0.080 mH 402.0 W 586.4 W 75 kA (200 ms) 113.3 kg 1000 V
6RX1800-4KK02
789 A AC
0.064 mH
362.7 W
564.6 W
75 kA (200 ms)
141.9 kg
1000 V
6RX1800-4KK03
830 A AC
0.061 mH
350.7 W
561.4 W
75 kA (200 ms)
153.4 kg
1000 V
6RX1800-4KK04
1245 A AC
0.041 mH
505.2 W
845.7 W
75 kA (200 ms)
169.7 kg
1000 V
6RX1800-4KK05
1577 A AC
0.032 mH
716.8 W
1093.8 W
75 kA (200 ms)
226.1 kg
1000 V
6RX1800-4KK06
1660 A AC
0.031 mH
596.0 W
1011.8 W
75 kA (200 ms)
257.2 kg
1000 V
6RX1800-4KK07
2158 A AC
0.024 mH
484.8 W
1185.6 W
75 kA (200 ms)
360.2 kg
1000 V
Table 6- 8 3-phase line reactors, rated voltage = 830/950 V AC, uk = 4%
Article number
Rated current
Inductance
Copper
losses
Total
losses
SCCR
Weight
Rated insulation
voltage
830 V:
6RX1800-4LK00
789 A AC
0.077 mH
312.0 W
532.1 W
75 kA (200 ms)
205.2 kg
1000 V
6RX1800-4LK01
1245 A AC
0.049 mH
692.4 W
1061.9 W
75 kA (200 ms)
222.4 kg
1000 V
6RX1800-4LK02
1577 A AC
0.039 mH
479.4 W
1059.6 W
75 kA (200 ms)
308.5 kg
1000 V
6RX1800-4LK03
1826 A AC
0.033 mH
585.6 W
1269.0 W
75 kA (200 ms)
372.5 kg
1000 V
950 V:
6RX1800-4MK00
1826 A AC
0.038 mH
534.9 W
1303.5 W
75 kA (200 ms)
399.7 kg
1000 V
Table 6- 9 1-phase line reactors, rated voltage = 400 V AC, uk = 4%
Article number
Rated current
Inductance
Weight
Rated insulation
voltage
6RX1800-4DE00
3 A AC
16.977 mH
0.7 kg
600 V
6RX1800-4DE01
5 A AC
10.186 mH
1.5 kg
600 V
6RX1800-4DE02
10 A AC
5.093 mH
2.0 kg
600 V
6RX1800-4DE03
15 A AC
3.395 mH
2.3 kg
600 V
6RX1800-4DE04
25 A AC
2.037 mH
3.0 kg
600 V
6RX1800-4DE05
30 A AC
1.698 mH
3.8 kg
600 V
6RX1800-4DE06
40 A AC
1.273 mH
5.2 kg
600 V
6RX1800-4DE07 85 A AC 0.599 mH 9.6 kg 600 V
Connections:
3-phase reactors with rated current ≤85 A:
Terminal blocks
3-phase reactors with rated current >85 A:
Connecting lugs
1-phase reactors with rated current ≤30 A:
Terminal blocks
1-phase reactors with rated current >30 A:
Connecting lugs
