Connecting
6.7 Fuses
SINAMICS DCM DC Converter
150 Operating Instructions, 12/2018, A5E34763375A
6.7.2
Fuses for the armature circuit
2Q devices: 400 V, 575 V, 690 V, 830 V and 950 V
Table 6- 11 Phase fuses
Device
3 x phase fuses Siemens ЯU
3x phase fuses Siemens ЯU for DCM
packages
Article number
I/U [A/V]
Article number
I/U [A/V]
Article number
I/U [A/V]
6RA8025-6DS22-0AA0
60 / 400
3NE1817-0
50 / 690
3NE1817-0
50 / 690
6RA8025-6GS22-0AA0
60 / 575
3NE1817-0
50 / 690
3NE1817-0
50 / 690
6RA8028-6DS22-0AA0 90 / 400 3NE1820-0 80 / 690 3NE1820-0 80 / 690
6RA8031-6DS22-0AA0
125 / 400
3NE1021-0
100 / 690
3NE1021-0
100 / 690
6RA8031-6GS22-0AA0
125 / 575
3NE1021-0
100 / 690
3NE1021-0
100 / 690
6RA8075-6DS22-0AA0
210 / 400
3NE3227
250 / 1000
3NE3227
250 / 1000
6RA8075-6GS22-0AA0
210 / 575
3NE3227
250 / 1000
3NE3227
250 / 1000
6RA8078-6DS22-0AA0
280 / 400
3NE3231
350 / 1000
3NE3231
350 / 1000
6RA8081-6DS22-0AA0
400 / 400
3NE3233
450 / 1000
3NE3333
450 / 1000
6RA8081-6GS22-0AA0
400 / 575
3NE3233
450 / 1000
3NE3333
450 / 1000
6RA8085-6DS22-0AA0
600 / 400
3NE3336
630 / 1000
3NE3336
630 / 1000
6RA8085-6GS22-0AA0
600 / 575
3NE3336
630 / 1000
3NE3336
630 / 1000
6RA8087-6DS22-0AA0
850 / 400
3NE3338-8
800 / 800
3NE3338-8
800 / 800
6RA8087-6GS22-0AA0
800 / 575
3NE3338-8
800 / 800
3NE3338-8
800 / 800
6RA8086-6KS22-0AA0
720 / 690
3NE3337-8
710 / 900
3NE3337-8
710 / 900
It is not permissible to use different fuse types together.
Table 6- 12 Arm fuses
Device
Siemens ЯU arm fuses
Article number
I/U [A/V]
Qty
Article number
I/U [A/V]
6RA8091-6DS22-0AA0
1200 / 400
6
3NE3338-8
800 / 800
6RA8090-6GS22-0AA0
1100 / 575
6
3NE3338-8
800 / 800
6RA8090-6KS22-0AA0
1000 / 690
6
3NE3337-8
710 / 900
6RA8088-6LS22-0AA0
950 / 830
6
3NE3337-8
710 / 900
6RA8093-4DS22-0AA0
1600 / 400
6
6RY1702-0BA02
1000 / 660
6RA8093-4GS22-0AA0
1600 / 575
6
6RY1702-0BA02
1000 / 660
6RA8093-4KS22-0AA0 1500 / 690 6 6RY1702-0BA03 1000 / 1000
6RA8093-4LS22-0AA0
1500 / 830
6
6RY1702-0BA03
1000 / 1000
6RA8095-4DS22-0AA0 2000 / 400 6 6RY1702-0BA01 1250 / 660
6RA8095-4GS22-0AA0
2000 / 575
6
6RY1702-0BA01
1250 / 660
6RA8095-4KS22-0AA0
2000 / 690
12
6RY1702-0BA04
630 / 1000
6RA8095-4LS22-0AA0
1900 / 830
12
6RY1702-0BA04
630 / 1000
6RA8096-4GS22-0AA0
2200 / 575
6
6RY1702-0BA05
1500 / 660
