Connecting
6.7 Fuses
SINAMICS DCM DC Converter
Operating Instructions, 12/2018, A5E34763375A
151
Device
Siemens ЯU arm fuses
Article number
I/U [A/V]
Qty
Article number
I/U [A/V]
6RA8096-4MS22-0AA0
2200 / 950
12
3NC3438-6
800 / 1100
6RA8097-4KS22-0AA0
2600 / 690
12
3NC3341-6
1000 / 1000
6RA8097-4GS22-0AA0 2800 / 575 12 3NC3341-6 1000 / 1000
6RA8098-4DS22-0AA0
3000 / 400
12
3NC3341-6
1000 / 1000
The arm fuses are included in the device. No external semiconductor fuses are required.
It is not permissible to use different fuse types together.
2Q devices: 480 V
Table 6- 13 Phase fuses
Device
3 x phase fuses
Siemens ЯU
3x phase fuses
Siemens ЯU for DCM
packages
3 x phase fuses
Bussmann ЯU
3 x phase fuses
Bussmann ЯU
Article
number
I/U
[A/V]
Article
number
I/U
[A/V]
Article
number
I/U
[A/V]
Order No.
I/U
[A/V]
Order No.
I/U [A/V]
6RA8025-
6FS22-0AA0
60 / 480 3NE1817-0 50 /
690
3NE1817-0 50 / 690 170M1565 63 /
660
FWH-60B 60 / 500
6RA8028-
6FS22-0AA0
90 / 480 3NE1820-0 80 /
690
3NE1820-0 80 / 690 170M1567 100 /
660
FWH-100B 100 /
500
6RA8031-
6FS22-0AA0
125 /
480
3NE1021-0 100 /
690
3NE1021-0 100 /
690
170M1568 125 /
660
FWH-125B 125 /
500
6RA8075-
6FS22-0AA0
210 /
480
3NE3227 250 /
1000
3NE3227 250 /
1000
170M3166 250 /
660
FWH-225A 225 /
500
6RA8078-
6FS22-0AA0
280 /
480
3NE3231 350 /
1000
3NE3231 350 /
1000
170M3167 315 /
660
FWH-275A 275 /
500
6RA8082-
6FS22-0AA0
450 /
480
3NE3233 450 /
1000
3NE3333 450 /
1000
170M3170 450 /
660
FWH-450A 450 /
500
6RA8085-
6FS22-0AA0
600 /
480
3NE3336 630 /
1000
3NE3336 630 /
1000
170M4167 700 /
660
FWH-600A 600 /
500
6RA8087-
6FS22-0AA0
850 /
480
3NE3338-8 800 /
800
3NE3338-8 800 /
800
170M5165 900 /
660
FWH-800A 800 /
500
FWH-... and FWP-... fuses are mechanically incompatible with 3NE... and 170M... fuses.
It is not permissible to use different fuse types together.
Table 6- 14 Arm fuses
Device
Siemens ЯU arm fuses
Article number
I/U [A/V]
Qty
Article number
I/U [A/V]
6RA8091-6FS22-0AA0
1200 / 480
6
3NE3338-8
800 / 800
The arm fuses are included in the device. No external semiconductor fuses are required.
It is not permissible to use different fuse types together.
