Depth / Zoom
Adjusts the scanning depth and magnifies the image
Rotate clockwise / counter-clockwise to increase /
decrease depth.
Press to activate zoom.
Rotate to change region of interest (ROI) size and press to activate.
Press again to exit zoom.
Note: Zoom available in live or frozen images.
HD Zoom
Displays a high density zoom
Press to activate.
Rotate the Depth / Zoom to increase / decrease ROI.
Press Depth / Zoom or HD Zoom to activate.
Dual
Displays two separately acquired images side-by-side
Press Dual to activate and toggle between images.
Press the 2D key to exit.
