Color and Spectral Doppler
Spectral Doppler Control Panel
Control Panel Controls Function
D (pulsed wave) Doppler
and CW (continuous
wave) Doppler
Enters / exits spectral Doppler or adjusts overall spectral Doppler gain
Press to activate / deactivate.
Roll trackball to position Doppler gate.
Press D or CW to activate the strip.
Rotate to adjust overall spectral Doppler gain.
Note: Available on live image only.
TGO (TGO Technology)
One button optimization of spectral Doppler gain, baseline, and scale
With Doppler spectrum active, press to activate.
Press twice to exit TGO.
Note: Available on live image only.
Update / View
Alternates between the Doppler spectrum and the 2D image
Press to alternate between Doppler / 2D.
Note: Available on live image only.
30
