M-mode Soft Keys
Soft Key Controls Function
MultiHertz (frequency)
Adjusts Frequency for 2D image and M-mode strip
Rotate clockwise to increase resolution.
Rotate counterclockwise to increase penetration.
Note: Available on live image only.
Maps
Processing curves that assign echo amplitudes to gray shades in the
M-mode sweep
Map choice is displayed from low to high contrast.
Note: Available on live or frozen image.
Tint
Colorizes the M-mode sweep
Press and rotate for tints from 0 –15.
Note: Available on live or frozen image.
DR (Dynamic Range)*
Adjusts number of gray shades displayed in the M-mode sweep
Rotate clockwise for a softer / grayer sweep.
Rotate counterclockwise for increased contrast.
Note: Available on live or frozen image.
2D Mode and M-mode
Configurable for the touch screen controls and/or soft rotary keys.*
