Measurements and Calculations
Unlabeled Measurements
Perform Measurement
1. Press
2. Select the desired measurement type and
Press Caliper.
3. Roll the trackball to position the first caliper.
4. Press
to anchor
Measurements can be performed on
frozen, CINE and stored images
TIP
5. Roll the trackball to position the second
caliper.
6. Press
to complete the measurement.
Unlabeled measurements do not enter
into the exam report.
38
