Map

Selects a processing curve that assigns echo amplitudes to gray

shades in the Doppler spectrum

Select desired Map from A – H.

Note: Available on live or frozen image.

Tint

Colorizes the Doppler spectrum

Select desired Tint from 0 – 11.

Note: Available on live or frozen image.
