Soft Key Controls Function
MultiHertz (frequency)
Adjusts the color Doppler frequency independent of the 2D frequency
Rotate to increase / decrease.
Note: Available on live image only.
Maps
Selects a processing curve that assigns the velocity / velocity variance
(for Color) or flow amplitudes (for Power) to a range of colors
Maps choices are A – I.
Note: Available on live or frozen image.
P (Transmit Power)
Acoustic energy delivered to the patient in color Doppler mode
Increase / decrease to adjust the transmit power.
Note: Available on live image only. Changes Mechanical and Thermal
Indices displayed.
Color and Spectral Doppler
Color Doppler Soft Keys
28
