Map
Processing curves that assign echo amplitudes to gray shades
Maps A – I are from low to high contrast.
Maps 1– 3 are customizable maps (Modify Map).
Note: Available on live or frozen images.
Tint
Colorizes the grayscale image
Press and rotate for tints from 0 –15.
Note: Available on live or frozen images.
Rotate
Adjusts image orientation in 90 degree increments
Rotate to adjust.
Note: Available on live image only.
Configurable for the touch screen controls and/or soft rotary keys.*
