Siemens Acvatix SAX Series User Manual

12 / 92
Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Engineering 2018-12-05
2.3.3 Rotary actuators
Product no. Stock no.
Angular
rotation
Torque
Operating
voltage
Positioning
signal
Spring
return
time
Pos.
time
LED
Manual
adjuster
Extra
functions
SAL31.00T10 S55162-A108
90°
10 Nm
AC 230 V 3-position
-
120 s
-
Press and
fix
-
SAL31.00T20 S55162-A110 20 Nm
SAL31.00T40 S55162-A111 40 Nm
SAL31.03T10 S55162-A109
10 Nm
30 s
SAL61.00T10 S55162-A100
AC 24 V
DC 24 V
DC 0…10 V
DC 4…20 mA
0…1000 Ω
120 s
P
Position
feedback,
forced control
SAL61.00T20 S55162-A102 20 Nm
SAL61.00T40 S55162-A103 40 Nm
SAL61.03T10 S55162-A101
10 Nm
30 s
SAL81.00T10 S55162-A104
3- position
120 s
- -
SAL81.00T20 S55162-A106 20 Nm
SAL81.00T40 S55162-A107 40 Nm
SAL81.03T10 S55162-A105 10 Nm 30 s
2.4 Ordering
Product no. Stock no. Description Quantity
SAX81.03 S55150-A103 Actuator 1
ASZ7.5 S55845-Z106 Potentiometer 1
Actuators, valves and accessories are supplied in individual packs.
Type Device Screws Waveinset
SAY..P..
- -
SAX..
- -
SAX../MO
- -
SAV..
- -
SAL..T10
- -
SAL..T20 2 pcs. M5 x 20 mm 1 pc. 11 mm
SAL..T40 2 pcs. M6 x 20 mm 1 pc. 14 mm
4
040U01
4
040U01
4040U32
Example
Delivery
Scope of delivery
