Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Glossary 2018-12-05
8 Glossary
8.1 Symbols
Caution, general danger – read the notes!
Caution, hot surface – read the notes!
Condition as supplied to costumer
Crosstip screwdriver (Pozidriv)
Slotted screwdriver
Screw wrench
Allen key
8.2 Terms
The complete product range of flexible and scalable control solutions, standardized
up to and including freely programmable solutions.
Specialized for HVAC applications.
A DIL switch shows the switching choices in the form of a place value system (dual
in line) in relation to basis 2 (on and off).
Nominal size: Characteristic for matching parts of the piping system.
Forced control serves for overriding automatic mode and is implemented in the
structure.
A HEX switch shows the switching choices in the form of a place value system
(hexadecimal system) in relation to basis 16 (0…9 and A…F).
Unit of pressure: 100 kPa = 1 bar = 10 mWS.
Nominal flow rate: Nominal flow rate of cold water (5…30 °C) through the fully
open valve (H
100
) at a differential pressure of 100 kPa (1 bar).
Light emitting diode.
Open communications protocol (client/server architecture), transmits data as binary
data.
RTU: Remote Terminal Unit.
PN class: Characteristic relating to the combination of mechanical und dimensional
properties of a component in the piping system.
Signal used to acquire the position, fed back via an input.
Refer "fail safe function".
Climatix
DIL switches
DN
Forced control
HEX switches
kPa
k
LED
Modbus RTU
PN
Position feedback
Spring return facility
