Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Handling 2018-12-05
First, observe "Special notes on mounting” (page 36).
Scope of delivery
Weather shield ASK39.1 2 UV-proof cable ties
· To protect the actuator when used outdoors, the weather shield must always be
fitted.
· If fitted several times, 2 UV-proof cable ties (800 x 4 mm) must be used.
· The manual adjuster cannot be used when the weather shield is mounted.
· SAX61../MO is not suitable for outdoor applications.
1
2
4040J30a
4
0
4
0
J
3
1
a
Weather shield
ASK39.1
Notes
