Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Functions and control 2018-12-05
Legend diagram
Positioning signal
range
Position LO Position UP
Position
feedback U
A DC 2…10 V 2 6 DC 0…10 V
B DC 0…5 V 0 3 DC 0…10 V
C DC 12…17 V C 3 DC 0…10 V
H Stroke or rotary angle
Acting direction: Direct (A, B, C)
Acting direction: Reverse (A', B', C')
Examples
