Siemens ELP 319 User Manual

Industry Mobility
Betriebsanleitung PZENTW A6Z08101637795/EN1/000/B 27
[7620] ELP 319 LANGE_THO A25000-X22-Q9-7-7620 of
DC013 20081022 Notice no.: 500000097465 33
Copyright (C) Siemens AG 1998 All Rights Reserved - 0000ZQ6U.doc
10.9 Stripping the Plastic-sheathed Flexible Cable
Figure 17 Stripping the plastic-sheathed flexible cable
For point openings below 70 mm, the terminal strip is to be placed between the two contact
arrangements. In this case the plastic-sheathed flexible cable must be stripped flush with the terminal
strip.
