7.4 Safety-minded Work

• The qualified staff referred to in Section 7.3 are responsible for job safety.

• The ELP 319 end position detector may only be operated if it is in perfect working order.

• The work must be carried out in such a way that human safety is not diminished nor the

operation of the ELP 319 end position detector impaired.

• As a rule, safety equipment must not be removed or put out of operation.

• Safety-minded work implies that staff are to be informed of incorrect actions and any faults

detected are to be reported to the authority or person responsible.

DANGER

No unauthorised modifications to the ELP 319 end position

detector are to be carried out.

7.5 Agents

The following detergents, lubricants and other agents are used for the ELP 319 end position detector:

Designation Application

• White spirit

Cleaning of parts

• Molub-Alloy 243 Arktic grease

Greasing of parts

• SAE 10 W/40 oil (do not use spray oils

containing turpentine or silicone)

Oiling of parts

• Flake graphite

Grase Cover lock

• De-icing agent

De-ice Cover lock

CAUTION

Prevent your skin from coming into contact with the above-

mentioned agents, in particular the grease! They (especially

grease) can irritate the skin or cause other allergic reactions. Only

apply them using gloves and appropriate tools (e.g. a brush).

7.6 Earthing of the Detector Housing

The detector housing must be connected to earth potential or, on electrified lines, to the railway

earthing system. For this purpose, use insulated copper wire-rope cable with the cross section

specified by the railway operator. Connect this earthing cable to the M16 earthing terminal of the

housing using a cable lug.
