Industry Mobility
Betriebsanleitung PZENTW A6Z08101637795/EN1/000/B 33
[7620] ELP 319 LANGE_THO A25000-X22-Q9-7-7620 of
DC013 20081022 Notice no.: 500000097465 33
Copyright (C) Siemens AG 1998 All Rights Reserved - 0000ZQ6U.doc
12.5 Functional Check after Maintenance Work
Operate the point machine by means of the crank handle until the mid-blade lock has an overlap of
min. 4 mm and the opening between stock rail and point blade is not greater than 58 mm. Check that
the roller of the contact lever is not engaged with the large notch (open point blade) and the contacts
have changed over.
Disengage the roller of the closed point blade. Is a "points trailed" indication being issued? If so, the
ELP 319 end position detector is correctly adjusted and fully operational.
