7.7 Tools
The following tools are required:
•
plastic hammer
•
slotted-head and Philips screwdrivers
•
set of Allen keys
•
socket set with extension bar
•
set of open-end or ring spanners
•
torque spanner with an adjusting range from 8 to 40 Nm
•
metal folding rule or similar measure
7.8 Transport of the ELP 319 End Position Detector
On account of its relatively high weight, the ELP 319 end position detector must be handled with care.
Please check all parts delivered immediately upon unpacking for completeness and any transport
damage.
DANGER
When transporting the ELP 319 end position detector, observe the
current regulations for the prevention of accidents, i.e. wear protective
gloves, use appropriate lifting equipment and take into account the
weight of the end position detector (27 kg), for example.
7.9 Storage of the ELP 319 End Position Detector
The end position detector can be stored for a short time (< 1 month) in the packaging supplied by the
manufacturer in the open air on a clean and dry surface.
When the end position detector is to be stored over a longer period of time, remove the foil and store
the end position detector at a weather-protected location in mounting position.
Do not pile up end position detectors.
